Vanguard VEO 5 234C Carbon Fiber Tripod featuring PH-36S Pan and Tilt Head

Name: Vanguard VEO 5 234C Carbon Fiber Tripod featuring PH-36S Pan and Tilt Head
SKU: VEO 5 234CPS36
Price: 219.99 USD
Availability: InStock

Availability:

In stock

Key Features of VEO 5 234CPS36

Maximum Load: 13.2 lb
Operating Height: 9.1 to 64 inches
Collapsed Size: 22.9 inches
PH-36S Pan-and-Tilt Head featuring Arca-Swiss Quick Release
Carbon Fiber Legs in 4 Sections with Twist-Lock Mechanisms
Integrated Easy Link Connector Thread
Weight: 3.8 lb

SKU: VEO 5 234CPS36
Condition: Brand New
Other Options: Opened, unused, or refurbished units may be available contact support.

$219.99

In stock

Vanguard VEO 5 234C Carbon Fiber Tripod with PH-36S Pan/Tilt Head

The Vanguard VEO 5 234C is a lightweight yet versatile carbon-fiber tripod that pairs 4-section, 23mm legs with the VEO PH-36S three-way pan-and-tilt head. It supports a load of up to 13.2 lb and reaches a working height range from about 9.1″ to 64″, while folding down to roughly 22.9″ for transport ? a practical balance of stability and portability for photo and video shooters.

Its hexagonal center column separates into a short column for low-angle shooting, and each carbon-fiber leg has a rubber foot with a retractable steel spike for grip on any surface. The included PH-36S head offers precise control on three separate axes, a panoramic base with a numbered scale, and an Arca-type quick-release plate. A padded carry bag is included.

Carbon-fiber 4-section legs; folds to about 22.9″ for travel
Height range roughly 9.1″ to 64″; up to 13.2 lb load capacity
PH-36S 3-way pan/tilt head with Arca-type quick release
Hexagonal center column converts to a short column for low angles
Retractable spiked rubber feet and included padded bag

SKU: VEO 5 234CPS36 Category: Carbon Fiber Tripod

Weight	4.98 lbs
Dimensions	24.8 × 5.7 × 4.7 in

Vanguard VEO 5 234C Carbon Fiber Tripod featuring PH-36S Pan and Tilt Head Specs

Key Specs	Camera Mounting	1/4″-20 Screw (Quick Release Plate: Arca-Type)
	Head Type	Pan & Tilt Head
	Drag Control	No
	Primary Material	Carbon Fiber
	Load Capacity	13.2 lb / 6 kg
	Maximum Working Height	64″ / 162.6 cm
	Minimum Working Height	9.1″ / 23.1 cm
	Closed Length	22.9″ / 58.2 cm
	Weight	3.8 lb / 1.7 kg
	Head	Camera Mounting	1/4″-20 Screw (Quick Release Plate: Arca-Type)
Head Type		Pan & Tilt Head
Base Mount		Flat Base with 3/8″-16 Female
Dimensions		Depth: 8.1″ / 20.6 cm Width: 7.0″ / 17.8 cm Height: 4.4″ / 11.2 cm
Pan & Tilt	Drag Control	No
	Independent Pan Lock	Yes
	Independent Tilt Lock	No
	Vertical Tilt	+90 to -60
	Lateral Tilt	-60 to +90
Legs	Primary Material	Carbon Fiber
	Leg Lock	Twist Lock
	Leg Sections	4
	Independent Leg Spread	Yes
	Leg Positions	3 Positions
	Foot Features	Retractable, Spiked
General	Load Capacity	13.2 lb / 6 kg
	Maximum Working Height	64″ / 162.6 cm
	Center Column	Yes (Faceted): Ballast Hook, Removable, Reversible, Split
	Max Height without Center Column	53.8″ / 136.7 cm
	Minimum Working Height	9.1″ / 23.1 cm
	Closed Length	22.9″ / 58.2 cm
	Accessory Mounting	2x 3/8″-16 Female Thread
	Bubble Level	Yes
	Detachable Monopod	No
	Weight	3.8 lb / 1.7 kg
	Packaging Info	Package Weight	4.98 lb
Box Dimensions (LxWxH)	Packaging Info	24.8 x 5.7 x 4.7″
